Features and Benefits

• Basic fault self-diagnosis with LCD read out
• Built-in multi-purpose filtration
• Electronic temperature control for constant temperature at around 97°C
• Easy access for service and cleaning
• Long-life incoloy elements
• Boil dry protection
• Stainless steel drip tray included
• 28 litres per hour output
• WRAS Approved

Installation
Easy to install on a stable worktop.

Plumbing
Designed for direct connection to a potable cold water supply using the 1.5 metres (3/4” BSP) hose supplied. An isolating valve should be installed between the supply and the heater. Rear supply connection and choice of rear (optional additional kit) or front overflow as standard.

Electrical
To be connected to 230 volt supply with a suitable break capacity of 13 amps.

Construction
Brushed stainless steel case.
Stainless steel heating chamber.
Low voltage switching.
Two safety cut-outs.

TECHNICAL DATA

• Power loading (kW): 3
• Heat-up time (mins): 32
• Recovery Rate (litres): 0.5
• Stand by Power (kW/h): 0.088
• Rapid Draw-Off (litres): 11
• Rapid Draw-Off (cups): 60
• Hourly Output (litres): 27
• Hourly Output (cups): 162

(* Based on 6 Cups Per Litre)
