Maidaid EVO 402 Under Counter Glasswasher

• Evo 402 Rack size 400 x 400mm
• Maximum useable height 295mm
• Dimensions W465 x D560 x H690mm
• Height excludes adjustable feet which will add 5 - 15mm
• Three selectable cycle times ranging from 90-715sec
• Power 2.8kW
• 13 Amps required

Key Points

• 2 year warranty
• NEW polychromatic LCD display and user interface giving uncomplicated machine status updates
• NEW four button control fascia with a special programs button
• NEW cycle give a complete refresh of the wash water
• Designed for the most demanding environments
• Reduced water consumption
• Double skinned misimising both acoustic output and reduced heat loss
• Breaktank as standard
• Drain pump as standard
• Surface scrap tray filters supplied as standard
• Improved triple wash tank filtration system
• Detergent and rinse aid delivered by precise peristaltic pumps
• Priming and dosing of chemicals enabled from fascia controls
• Supplied with two open cup/glass racks
• Hi-level information retrieval to aid both installation and service technicians
• Three standard cycle options
• Extensive range of special cycles
• PLATES cycle automatically changes parameters to suit plate washing
• Comprehensive automatic self-cleaning cycle
• Suitable for hot (max 50°C) or cold water supply at 2 to 4 bar dynamic supply pressure
• Machines fitted to cold water supplies will not be capable of running repeated short cycles.
• The cycle time will automatically be extended to allow recovery of correct operating temperatures
• Wash temperature 60°C (adjustable)
• Rinse temperature 65°C (adjustable) 78°C when PRO plates cycle selected
